If you do any interior trim or architectural mill work check out Gary Katz Online. there are lots of great information that any woodworker could find useful.
Read more...
I learn a while ago, the hard way I might add to keep notes while I work in the shop. First it was a spiral notebook like the one you get for school. I have three of them now, full of old shop notes, mostly notes and cut list from old jobs I have worked on. I also have a three ring binder that I paste pictures of furniture or other things that catch my eye. I keep sketches of furniture or what ever else that I think will be useful to me when I am working on designing a piece in this folder also.
Last year I found this little notebook that is filled with 1/8" graph paper, its small with a hard cover just the right size to keep in my toolbox. I really like to have this available while I work, mostly because that is when I find I am at my most creative. Its usually when I'm visualizing what I am building that I start coming up other ideas, some of them related to what I am building and some of them not. Having a notebook close by lets me jot those ideas down for a later use. This book is also where I write all my job notes and figure out the layout for cutting plywood so I can get the most yield from a each sheet ply, something I have found that saves me time and material. Having these notes let me reference a piece quickly in case I have to cut another piece for when I screw up. Plus if I get other cabinets the same size I all ready have the cut list. I also keep track of operational times which help me estimate future jobs.
I urge everyone to start keeping a notebook in your tool box and after a while you will find it will becomes a part of your tool kit just like your saw and plane is.
We went over most of the basic steps to get your flute started in my past posts like:
1, Wood section, I like pine or Fir but most woods will work.
2, Tools, a gouge and a block plane will do most of the work, and a coping saw for the bird effigy, or if your making a carved head
3, Dimensions, I like my flute to have a 7/8 bore but 3/4 and 1" will work. The length of the flute depends on the key.
Now here are some tips I would like to share. I drill all my holes before I glue the two pieces together, this lets me sand any splinters away that the drilling creates. I like to sand the inside to a 320 grit this I feel helps improve the sound. I also put 2 or 3 coats of mineral oil on the inside just be careful not to get any on the gluing surface.
Finishing the inside will stops the wood from absorbing moisture as you play it, giving it a more consistence sound. I also use a 1 to 1 glue size on the end grain of the sound block, this is the block that separates the two chambers this help to strengthen that area since its a weak area and its also a end grain that will absorb the moisture from your breath.
Next thing to do is glue the two parts together. I use plenty of clamps and don't over tighten the clamps since you are only gluing a 1/4 surface. I keep mine in the clamps for a whole day, and I use a waterproof glue like Titebond 3. Next you have to decide if you are carving a head on the end of the flute. I carved an eagle on this one. I glue an extra piece of 3/4 x 5 wood to the top.
Next comes the fun part shaping the flute, since I was carving a head I started my planing the sides flat and close to the 1/4" wall thickness, then I drew a out the lines of the eagle.
I used a coping saw to rough out the shape.
Then I planed the flute round. this is the part that most people every fears, but its really easy just watch the direction gain and take your time. You are looking for walls that are about a 1/4 " thick all the way around. If you tap the wood you can almost tell where you need to take off more just by the sound, when you get close its time to sand. I work my way from 100 to 220, and if you are carving now is the time to do most of your carving.
When you get the all the carving and the thickness where you want it, its time to work on the sound. I drill all the holes to a 1/4, then I use a fine file to clean the holes. I file the angle on the reed hole at about a 45* ankle.
Now before the flute will play you will need two more pieces, and they are the nest and the bird, the nest is a veneer that is 3/4 x 3" with a 1/4 x 1 slot cut into it, this lets the air from the first chamber go across the reed hole with the help of the bird, which is a effigy that sits on the nest.
I tie the bird to the flute with a leather cord with the nest under it.
You also need to drill a 1/4 hole in the mouthpiece end of the flute to the 1st chamber, now blow into it and get all the chips out.
When you get everything assembled blow though the mouthpiece and see if you get a sound, you may have to move the bird around a little while you blow to get the first sound, now just keep working it till you are happy with it, this takes a little while so stick with it. If you are planning to put a finish on I suggest a nontoxic one like mineral oil or walnut oil then bluff it with some beeswax.
most times mine play pretty well at this point, but if you are musical you might want to adjust the scale by filing the key holes till you match the scale.
I hope you enjoyed this project and if you have any questions please contact me and I will help anyway I can.
Joey
Recently I was asked to review Krylon’s new line of outdoor wood stain and sealer with a UV protector in a 12 OZ spray can. I was more than happy to test this new product.
I worked in shop back in early 90s that sprayed their stain on 75% of their work. I wonder why more shops didn’t do this; it certainly speeded up that part of the finishing process and with the right person behind the spray gun gave great results. The only problem is the process demands an outlay of money and a little time to master the technique to get setup to spray stain, and not all stains work well when sprayed. This is why most hobbyist and small shops don’t get involved with the spraying their stains.
Krylon to the rescue; Krylon has come out with a stain in their standard spray cans that will let anyone spray stain without all the hassles. I tried their product this afternoon and I can tell you, I really liked it. I made a small table for my porch out of some old 2 x 4s I had and then mounted it on a base that I made a few years ago. I was a little worried about the end gain absorbing the stain and appearing darker so I put a coat of diluted sealer on them. I sanded the top with some 100 grit on my sander. Then I sprayed a light coat on the top, starting with the edges. The can sprayed nice with its 360 adjustable nozzle that lets you change from a vertical to a horizontal flow. After I laid down a thin coat I wiped it off with a clean rag. The color was a little lighter then I was wanting and uneven. I should point out that I did not seal the top just the end gains on the edges. I let this coat dry for about an hour then I spray a second coat on this time I didn’t wipe off the stain I just let it dry, doing this gave me a nice even color across the whole top without hiding the grain pattern. I left it to dry for couple of hours then checked on it and still a little tacky to the touch.
My thoughts on this product, it’s easy to use and it will give you good results. I can see a lot of week end handy people using this along with crafters. It sprayed a nice even coat with no spitting and flowed nicely. Iit will save you time. I think just the time I spent staining the top without the time I waited for it to dry was about 6 minutes that includes clean up. That in its self is motivation to use it.
My only complains about the product is it only comes in a limited amount of colors for outdoor projects. I would love to see them come out with a line of indoor stains and more colors, maybe even some primary colors like red, blue, and green stains.
I plan useing this product on future projects, I have some outdoor chairs I need to build, and a trellis that needs stained and this product will be perfect for the job. So if you have some outdoor projects that you are planning give Krylon’s new stain a try, I am sure you will be pleased.
Joey
Read more...
I have made my own scrapers for a long time, all you need is a saw plate. I find them all the time at the flea market for a buck or two.
I used a roto zip with a metal cut off wheel to cut them, But I have cut them with a file or a hack saw. I like saw plate because most are made of good steel.
The larger of the three I will grind to fit a molding that I need the smaller one is for the insides of my flutes I make, and the last one I will make a sq scraper out of. Normally, I get a few more scrapers out of a saw, but I am going to use the shorten end of the saw to make a handsaw that will fit my grandson, since most are way to big for his little hand.
Sunday as you walked though the F&S Publications front door the first think that greeted you was this wonderful Demi Loom table with it wonerful inlay work. This was a display from the Society of American Period Furniture Makers or the SAPFM for short. Although I didn't get a chance to chat with the gentlemen at the booth because he was pretty busy with a group of men but I did get to talk to a very nice lady who was giving a demonstration on prepping satinwood stringing for inlay like the one in the photo below.
The guys at Pop Woodworkers had plenty of booths presenting lots of great information, along with the planes Lie Nelson had on display I was in tool heaven. This is great because I'm one of those kind of guys that needs to see and hold what I am buying, that is one reason I don't buy a lot off the Internet unless it is something that I have had a chance to check out. I got to hold all the tools I have been wanting to buy from the catalog and this in turn has caused me to reconsider a couple of them for another tool, mainly because of feel and fit.
I didn't really buy much, but I did pick up a couple of marking knife kits from Czeck Edge Tools one for my self, and one to make for a gift.
One of the best parts of the day was meeting and talking to Jameel from Benchcraft what a nice guy I really enjoyed talking to him. and his product is top notch I don't think there is any better on the market.
Another nice guy is Ron Hock from Hock Tools we talked for a little while and I got a couple of balsa airplanes from him for my grandsons. I do plan on ordering some new irons for a #6 and a # 3 Stanley from him later this year. Chris was showing his little girl how to plane wood in the fore ground at Ron's booth.
A big surprise was Bob giving pointers on low flow toilets in the men's rest room. I don't know where they had Norm hiding, maybe he was in the ladies room, who knows?
All in all it was a nice event for me and my wife. She wants to learn how to do inlay now so that's cool. I got to talk to a couple of the guys from the magazine and sneak a peek at Megan's LVL bench, talked to Glen Drake again he was great as always I really love his tools they are well made and comfortable.
I hope they do this again next year and maybe I'll have a little more time and money..
Be sure to check out Big Dave's Woodworking for his take on the event.
Joey
